FRPP Q41F-10S Flanged Double Union Ball Valve DN15-100 GB Standard

Competitively priced, ultra-durable, new gray-black FRPP flanged double-jointed socket ball valve for the chemical water industry.
Model Number: Q41F-10S
Color: Gray-black
Connection: Flanged
Drive Mode: Manual
Channel: Straight-Through
Structure: Fixed Ball Valve
Function: Bypass valve
Temperature Resistance: High Temperature
Applications: Industrial Use, Water Industry Use
Trademark: KXPV
Size Range: DN15-DN100
Origin: Ningbo, Zhejiang

Pressure Class: 1.0Mpa(10bar)

Product Structural Features

1. The PTFE seat of double-union ball valve can be adjusted tightly.
2. Double O-rings provide double leak protection.
3. Exquisite appearance, smooth surface, fine processing, full flow design.

App Temperature Bound List



Material        Medium temperature℃ Material Medium temperature℃
PVC-C -20℃~+95℃ PVC-U -5℃~+45℃
FRPP -20℃~+120℃ PPH -20℃~+110℃
PVDF 40℃~+150℃
