PVC-C Female Threaded Adapter DN15-50 GB Standard

Wholesale light gray PVC-C Female Threaded Adapter DN15-DN50 Lightweight Plastic Quick-Fit Female Threaded Straight Connector Industrial Water Supply Fittings
Place of Origin: China
Brand Name: KXPV
Material: PVC-C
Technics: Forged
Connection: socket
Shape: Equal
Head Code: Square
Color: Light Gray
Sizes: DN15-DN50
Application: Industry
Packing: Carton Box
Working Pressure: 1.6Mpa
Delivery Time: 7 Days
MOQ: 1 Piece
Supply Ability: 10000 Piece / Pieces per Month

App Temperature Bound List
Material        Medium temperature℃ Material Medium temperature℃
PVC-C -20℃~+95℃ PVC-U -5℃~+45℃
FRPP -20℃~+120℃ PPH -20℃~+110℃
PVDF 40℃~+150℃

Product Structural Features

1. Superior Chemical Resistance: Wide operating temperature range -20°C to 95°C, heavy ion content in the medium meets ultrapure water standards, and hygienic properties meet national health standards.
2. Excellent strength, toughness, and chemical corrosion resistance.
3. Durability: Excellent aging and UV resistance significantly extend the service life of other piping systems.
4. Low thermal conductivity: Approximately 1/200 that of steel; self-extinguishing flame retardancy.
5. Lightweight: Lightweight, equivalent to 1/5 of steel pipe and 1/6 of copper pipe.
6. Low resistance, high flow rate: Smooth, clean pipe surface, minimizes friction and adhesion when conveying fluids.
7. Easy installation, low cost: Adhesive and threaded connections are available, with glue being the most convenient.

Dimension List

DN D d1 d2 G L Z S e
15  27  20  16  Rc1/2 38  16  28  3.5
20  32  25  21  Rc 3/4 42  19  34  3.5
25  40  32  27  Rc1 47  22  42
32  50  40  35  Rc 1-1/4 54  26  52
40  61  50  43  Rc1-1/2 59  31  61  5.5
50  75  63  54  Rc2 70  38  75
65  88  75  69  Rc 2-1/2 80  44  88  6.5
