FRPP Pipes DN15-600 GB Standard

Custom-made latest design white high-pressure FRPP circular oval pipe 20mm-600mm PN10 water supply plastic irrigation pipe
Place of Origin: Zhejiang. Ningbo
Brand Name: KXPV
Material: FRPP
Specification: DN15-DN600
Length: 4000mm
Standard: DIN
Connection Method: Adhesive Bonding
Packaging: Plastic Film
Working Pressure: PN10
Colour: White
Base Material: FRPP
Delivery Time: 7 Days
Minimum Order Quantity: 1 Piece
Supply Capacity: 100,000 Metres/Month

Product Structural Features
FRPP (reinforced polypropylene) incorporates glass fiber within polypropylene, overcoming its inherent mechanical weakness. It can withstand corrosion from highly concentrated acids and alkalis with a pH range of 1-14, maintaining excellent corrosion resistance while operating in temperatures ranging from -20°C to 120°C. FRPP offers low cost, a long service life, and easy installation, making it widely used in industries such as steel, metallurgy, petroleum, chemicals, fertilizers, pharmaceuticals, power generation, wastewater treatment, copper foil, polysilicon, rare earth metals, graphite, new energy, energy storage, electronics and semiconductors, and chlor-alkali.
App Temperature Bound List
Material        Medium temperature° C Material Medium temperature° C
PVC-C -20℃~+95℃ PVC-U -5℃~+45℃
FRPP -20℃~+120℃ PPH -20℃~+110℃
PVDF 40℃~+150℃
PVC-U Pipes

DN D L
(mm)
1.0MPa 0.8MPa 0.6MPa 0.4MPa
Φmm S
(mm)
KG/M S
(mm)
KG/M S
(mm)
KG/M S
(mm)
KG/M
15  20  5000  2.1  0.12
20  25  5000  2.5  0.17
25  32  5000  0.26
32  40  5000  3.2  0.36
40  50  5000  4.2  0.58
50  63  5000  5.2  0.9  4.3  0.76  3.3  0.59  2.8  0.51
65  75  5000  6.2  1.28  5.1  107  3.9  0.83  0.65
80  90  5000  7.5  1.85  6.1  153  4.7  1.2  3.2  0.83
100  110  5000  9.1  2.75  7.5  23  5.7  1.78  3.9  1.24
125  140  5000  11.6  4.45  9.5  3.7  7.2  2.85  2.02
150  160  5000  13.3  5.85  10.8  4.8  8.3  3.76  5.7  2.63
200  225  5000  18.7  11.5  15.2  95  11.6  7.4  7.9  5.2
250  280  5000  23.2  17.8  18.9  14.72  14.4  14.1  9.9  7.98
300  315  5000  26.1  22.5  21.2  8.6  16.2  14.5  11.1  10.07
350  355  5000  29.4  28.6  23.9  236  18.3  18.5  12.5  12.8
400  400  5000  33.2  36.5  26.9  2994  20.6  23.32  14.4  16.6
450  450  5000  30.5  382  23.3  29.7  15.8  20.5
500  500  5000  33.9  472  25.7  36.4  17.6  25.4
600  630  5000  24.3  44
