PPH Eccentric Reducer DN65*500-200*150 GB Standard

Earthy Yellow PPH  Butt-Weld Reducers DN65*500-200*150 Custom Industrial plastic pipe cap fittings for chemical and water supply
Place of Origin: China
Brand Name: KXPV
Technics: Forged
Connection: socket
Material: PPH
Shape: Equal
Color: Earthy Yellow
Head Code: Square
Size: DN65*500-200*150
Application: Industry
Packing: Carton Box
Working Pressure: 1.6MPA
Delivery Time: 7 Days
MOQ: 1 Piece

App Temperature Bound List
Material        Medium temperature℃ Material Medium temperature℃
PVC-C -20℃~+95℃ PVC-U -5℃~+45℃
FRPP -20℃~+120℃ PPH -20℃~+110℃
PVDF 40℃~+150℃

Product Structural Features

1. High Crystallinity
Made from a single polypropylene monomer, the molecular chain contains no ethylene monomers; the molecular chain is highly regular and offers a long service life.
2. Excellent Corrosion Resistance
It can withstand corrosion from high-concentration acids and bases within a pH range of 1-14.
3. Heat-Resistant, Insulating, and Energy-Saving
It can operate in temperatures from -20°C to 110°C. Its low thermal conductivity provides excellent insulation performance.
4. Reliable Connection
The hot-melt joints are stronger than the pipe itself, preventing them from breaking due to soil movement or loads.
5. Excellent Construction Performance
This product is lightweight, features a simple welding process, is easy to install, and offers a low overall cost, suitable for complex process piping. PPH piping systems are widely used in industries such as electroplating, etching, chemicals, pharmaceuticals, wastewater treatment, and environmental engineering.

PPH Butt Welding Eccentric Reducer

DN D1 S1   D2 S2 L H1 H2
50X32 63  5.8    40  3.7  95  45  45
50X40 63  5.8    50  4.6  95  45  47
65X50 75  6.9    63  5.8  45  73  180
80X65 90  8.2    75  6.9  50  82  210
100X80 110  10    90  8.2  55  80  235
150X100 160  14.6    110  10  75  88  280
200X150 225  20.5    160  14.6  80  110  310
