PVC-C Pipes DN15-600 GB Standard

Large Diameter Gray PN16 Gray Black 20mm 600mm DIN Custom Square Round Plastic PVC-C Conduit Drain Pipe
Place of Origin: Zhejiang, China
Brand Name: KXPV
Material: PVC-C
Specification: DN15-DN600
Length: 4000mm
Thickness: Custom
Standard: DIN
Connection: Socket Fusion
Packing: Plastic Film
Working pressure: PN10-16
Color: Gray
Raw material: PVC-C
Size: DN15-DN600
Usage: Industrial
Supply Ability: 100000 Meter / Meters per Month

Product Structural Features
PVC-C (chlorinated polyvinyl chloride) is a new engineering plastic with broad application prospects. Its chlorine content can reach up to 69%, and its operating temperature range extends from -20°C to 95°C. It is resistant to chemical corrosion from strong acids, alkalis, salts, fatty hydrochloric acids, oxidants, and halogens. Compared to PVC-U, it has greater tensile and flexural strength, as well as greater chemical and corrosion resistance. Its excellent aging and UV resistance give it a longer service life than other piping systems. It is widely used in industries such as steel, metallurgy, petroleum, chemicals, fertilizers, pharmaceuticals, power generation, sewage treatment, copper foil, polysilicon, rare earth metals, graphite, new energy, energy storage, electronics and semiconductors, and chlor-alkali.
App Temperature Bound List
Material        Medium temperature° C Material Medium temperature° C
PVC-C -20℃~+95℃ PVC-U -5℃~+45℃
FRPP -20℃~+120℃ PPH -20℃~+110℃
PVDF 40℃~+150℃
PVC-U Pipes

inch

D

L

S

mm

mm

1.6MPa

1. 0MPa

0. 8MPa

0. 6MPa

1/2"

20 4000 2 2

3/4"

25 4000 2.3 2

1"

32 4000 2.9 2

1-1/4"

40 4000 3 2

1-1/2"

50 4000 3.7 2.4 2

2"

63 4000 4.7 3 2.5 2

2-1/2"

75 4000 5.6 3.6 2.9 2.3

3"

90 4000 6.7 4.3 3.5 2.8

4"

110 4000 8.1 5.3 4.2 3.4

5"

140 4000 10.3 6.7 5.4 4.3

6"

160 4000 11.8 7.7 6.2 4.9

8"

225 4000 16.6 10.8 8.6 6.9

10"

280 4000 20.6 13.4 10.7 8.6

12"

315 4000 23.2 15 12.1 9.7

14"

355 4000 26.1 16.9 13.6 10.9

16"

400 4000 29.4 19.1 15.3 12.3

18"

450 4000 21.5 17.2 13.8

20"

500 4000 23.9 19.1 15.3

24"

630 4000 30.3 24.1 19.3

28"

710 4000 27.2 21.8

32"

800 4000 30.6 24.5

This standard is formulated in accordance with the national standard GB/T 18998.2-2003. Pipe lengths may be customised to meet customer requirements.
